Reverse osmosis (RO) Process is a membrane process of molecular filter to remove all dissolved minerals, inorganic & heavy metals. etc. Neer water system is very popular for its enviroment friendly activities, effectiveness, less power consumption, customised design etc. |
|
|
 |
 |
 |
| |
|
|
 |
Process of Industrial RO Plant : |
|
 |
Raw Water Pump : |
| |
To generat the pressure for down the lines system. |
| |
|
|
Pressure Sand Filter (PSF) : |
| |
The water is first filtered by pressure sand filter unit for removal of suspended matters and turbidity |
| |
|
|
Activated Carbon Filter (ACF) : |
| |
To removed colour, Odour, Chlorine, Oil & Grease from the raw water |
|
 |
|
| |
|
|
Micron Cartridge Filter (MCF) : |
| |
These are Pressure Vessels Fitted internally with spun or pleated cartridge element which removes micron sized particles. |
| |
|
|
Antiscalant Dosing System : |
| |
To prevent membrance from scaling (hardness) |
| |
|
|
High Pressure Pump : |
| |
A high pressure pump is provided for supplying the feed water to RO System at high pressure of 10-12 kg/cm2 |
| |
|
|
RO Membrane Element : |
| |
A Reverse Osmosis System rejects 90 - 95% of Total Dissolved Solids (TDS) |
| |
|
|
Treated (RO) Water : |
| |
To store Treated (Pure) Water in tank. |
| |
|
|
